KNOWLED Flex Light F200SR 30×120

FULL DESCRIPTION

The KNOWLED Flex Light F200SR 30×120 is a high-performance flexible RGB LED panel designed for professional video productions, photo shoots, and broadcasting environments. With a 250 W power output and a super-slim flexible design, it is perfect for complex lighting setups, tight spaces, or curved mounting. It offers full color control (RGB, HSI, CCT, GEL, XY), ultra-high color accuracy, and multiple remote control options including DMX512, CRMX and Bluetooth. Built to handle both studio and on-location scenarios, it features IP54-rated dust and splash resistance, making it a reliable and portable lighting solution.

KEY FEATURES

• Flexible construction: the panel can bend to fit tight spaces or curved surfaces.
• Full color spectrum: RGBW + CCT range from 1800 K to 10,000 K with green/magenta shift.
• 14 built-in lighting effects: including lightning, TV, fire, party, explosion, and more.
• Exceptional color accuracy: CRI ≥96 and TLCI ≥98, ensuring professional-grade results.
• Advanced control options: supports DMX512, RDM, LumenRadio CRMX, and Bluetooth app control (30 m range).
• Weather-resistant: IP54-rated for both panel and controller against dust and splashes.
• Flexible power input: works with 100–240 V AC or 14.8–26 V V‑mount batteries for mobility.

TECHNICAL SPECIFICATIONS

• Power consumption: 250 W
• Color temperature (CCT): 1800–10,000 K
• Green/Magenta adjustment: ±100%
• Dimming: 0–100% with 0.1% increments
• Dimming curves: Linear, S-curve, Exponential, Logarithmic
• Color modes: RGBW, HSI, GEL, XY, 14 preset FX
• CRI: ≥96, TLCI: ≥98
• Light output: 7350 lux @1 m (at 5600 K)
• Protection rating: IP54 (panel and controller)
• Control interfaces: DMX512/RDM, CRMX, Bluetooth
• Connectors: 5-pin XLR (DMX in/out), USB-A (for updates and 5 V 1.5 A power output)
• Panel dimensions: 30 × 120 cm
• Panel weight: 1.05 kg
• Controller weight: 2.8 kg
• Operating temperature: –20 °C to +45 °C
• Power input: 100–240 V AC or 14.8–26 V V‑mount battery

PACKAGE CONTENTS

• KNOWLED F200SR 30×120 flexible LED panel
• Controller with connection cable
• Metal X-bracket frame
• Softbox FS200 with fabric grid
• Inflatable softbox with pump and skirt
• Repair patch
• Adapter holder
• AC power cable
• Hard case / padded carrying bag
• User manual + 1-year warranty

FAQ

What lighting effects are included with the F200SR?

The panel offers 14 built-in FX presets, including lightning, candle, TV, party, fire, welding, SOS, explosion, and more.

Is it suitable for outdoor use?

Yes. The panel and controller are IP54-rated, making them resistant to dust and water splashes.

Can I power it with V‑mount batteries?

Absolutely. It supports V‑mount batteries between 14.8–26 V, ideal for mobile shooting environments.

How accurate is the color rendering?

With a CRI of ≥96 and TLCI of ≥98, the F200SR ensures professional-level color fidelity across all modes.

What control options are available?

You can control the light via DMX512, RDM, LumenRadio CRMX, or Bluetooth app (up to 30 meters).
