Blackmagic Cloud Store 320TB

Full Description

Blackmagic Cloud Store 320TB is high-performance flash network storage engineered for large media and multi-user access across post-production, broadcast and VFX. Its NVMe M.2 memory core with RAID 5 delivers speed and redundancy, while 4× 10G Ethernet let multiple users work concurrently at full bandwidth. Native SMB support ensures seamless compatibility with macOS and Windows without proprietary client software. The integrated HDMI output provides live status—capacity, cloud sync, user activity, hardware health, storage map and bandwidth graphs—for operational visibility.

Cloud Store integrates with Blackmagic Cloud to synchronize and distribute media across locations, accelerating proxy/full-res delivery for remote teams. Dedicated USB-C ports automate ingest from external USB drives and scheduled backups directly from the array. Up to 200 SMB clients are supported, making it a scalable shared solution for editors, colorists, sound and VFX artists working in 4K/8K/12K.

The design features dual internal power supplies, status indicators, and management via Ethernet/USB-C using the Blackmagic Cloud Setup utility with straightforward firmware updates. All key specs below are verified against the official Tech Specs.

Key Features

• 320TB NVMe M.2 with RAID 5: high speed + redundancy for cinematic media and multi-user workflows.
• 4× 10G + 2× 1G Ethernet: aggregate bandwidth and network flexibility.
• Native SMB: instant macOS/Windows compatibility, up to 200 clients.
• HDMI status out: capacity, cloud sync, user activity, hardware status, storage map, bandwidth graphs.
• USB-C Ingest and USB-C Backup: automatic ingest from USB drives and automated backups from the array.
• Blackmagic Cloud sync and services support (including AWS S3 per Tech Specs) for global media distribution.
• Dual internal PSUs for mission-critical reliability.
• Included software: Blackmagic Cloud Setup Utility and Blackmagic Proxy Generator Lite (download).

Technical Specifications

Connections

• 10G Ethernet: 4 × 100/1000/10G BASE-T (RJ-45)
• 1G Ethernet: 2 × 100/1000 BASE-T
• USB-C Ingest: 1 × USB 3.0 (up to 5Gb/s), automatic ingest
• USB-C Backup: 1 × USB 3.0 (up to 5Gb/s), automatic backup
• HDMI monitor out: 1 × 1080p50/59.94/60
• Computer interface: Ethernet (file access/config/updates), USB-C (config/updates)

File Sharing & Cloud

• Protocol: SMB
• Clients: up to 200
• Cloud sync: Blackmagic Cloud integration; AWS S3 supported per Tech Specs

Storage

• Type: NVMe M.2 SSD
• Total capacity: 320TB (20TB/80TB models also available)
• Redundancy: RAID 5 (distributed parity)
• External storage: USB disks (ExFAT/HFS+)

Display/Monitoring

• HDMI out: 1080p50/59.94/60
• Status UI: device name, capacity/usage, Cloud Sync status, user activity, hardware status, storage map, network bandwidth graphs
• Status indicator: underside glow white (normal) / red (disk or PSU fault)

Included Software

• Blackmagic Cloud Setup Utility
• Blackmagic Proxy Generator Lite
• Internal firmware updates via USB-C

Operating Systems

• macOS 14.3 Sonoma or later
• Windows 10 (64-bit), Windows 11

Power

• Power supply: 2 × internal 100–240V AC 50/60Hz
• Input: 1 × IEC C14
• Max power: up to 400W

Physical & Environmental

• Dimensions (approx.): 17 × 17 × 29.5 cm (W × D × H)
• Weight (approx.): 6 kg
• Operating temp: 0–40°C; Storage temp: −20–60°C; Humidity: 0–90% non-condensing

Dimensions/weight from a professional reseller when not listed in the visible Tech Specs section.

In the Box

• Blackmagic Cloud Store 320TB
• Welcome wallet with software download QR code

Software (Cloud Setup Utility, Proxy Generator Lite) is provided via download. The official list does not mention included cables.

Use Cases

• Collaborative editing in SMB with dedicated 10G ports for edit, color and VFX rooms.
• Multi-site sync via Blackmagic Cloud and S3 for rapid proxy delivery and selective replication.
• Automated ingest & backup over USB-C for shuttle drives and scheduled protection.
• HDMI status monitoring on control-room screens for live performance insight.

Compatibility & Requirements

• Recommended 10G network (10G switch, Cat6A or better).
• SMB-capable macOS/Windows clients.
• Blackmagic Cloud account for advanced cloud features; S3 services as required.

FAQ (snippet-ready)

How fast is the 320TB Cloud Store?

The NVMe core and four 10G ports deliver multi-user throughput that can saturate each 10G link under real-world conditions (network/client dependent).

Do I need proprietary client software?

No. File access is via SMB on macOS/Windows. Management uses the Blackmagic Cloud Setup utility.

Can it sync to the cloud?

Yes. Blackmagic Cloud is integrated and the Tech Specs list AWS S3 sync support.

Is power redundant?

Yes. There are two internal power supplies (100–240V AC).

What’s included in the box?

The Cloud Store unit and a welcome wallet with software download QR code.
