ATEM Micro Camera Panel – Compact Control Panel for ATEM Switchers

The ATEM Micro Camera Panel from Blackmagic Design is a hardware control panel designed to provide a professional switching experience in a compact and portable format. Ideal for live productions, mobile studios, events, and streaming, this panel allows for precise and intuitive control of ATEM switchers, enhancing operational efficiency and production quality.

With a layout similar to the advanced ATEM panels, the ATEM Micro Camera Panel integrates high-quality backlit buttons, a manual fader for smooth transitions, and versatile connectivity via USB-C and Bluetooth. Its compatibility with the ATEM Software Control software makes it an ideal solution for professionals who need reliable, portable control.

Main Features

• Professional and Compact Design: Layout similar to the ATEM Advanced Panels, with backlit buttons and a manual fader for precise control.
• Extended Control: Two rows of ten buttons for program and preview, with a shift button to access up to 20 sources.
• Advanced Functions: Dedicated buttons for upstream and downstream keyers, transitions, preview transitions, macros, and four M/E buttons.
• Versatile Connectivity: Connects to your computer via USB-C or wirelessly via integrated Bluetooth.
• Software Compatibility: Works alongside the ATEM Software Control software, offering full control of the switcher.
• Portability: Built-in rechargeable battery with approximately 6 hours of runtime, ideal for on-the-go productions.

Technical Specifications

• M/E Mixing Lines: 1
• Direct Transition Points: 10
• Shifted Transition Points: 20
• Transition Button Type: Tri-color LED
• Preview Transition: 1
• Switching Buttons: CUT, AUTO
• Transition Types: DIP, DVE, STINGER, MIX, WIPE
• M/E Selection Buttons: 4
• Upstream Keyer Buttons: 4 with ON/OFF
• Downstream Keyer Buttons: 2 with ON/OFF
• Manual Transition Fader: 1
• Software Applications: Compatible with ATEM Software Control
• Operating Systems: macOS 13.0 Ventura, macOS 14.0 Sonoma or later; Windows 10 and 11
• Power Supply: Built-in rechargeable battery with on/off switch; USB-C port for external power and charging
• Power Consumption: Max 3W
• Battery Life: Approximately 6 hours under normal use
• Dimensions: 410 x 41 x 136 mm
• Weight: 1.05 kg
• Operating Temperature: 5° to 40° C
• Storage Temperature: -20° to 45° C
• Relative Humidity: 0% - 90% non-condensing

What's Included in the Box

• 1x ATEM Micro Camera Panel
• 1x USB-C Cable
• 1x User Manual

FAQ – Frequently Asked Questions

Q: Is the ATEM Micro Camera Panel compatible with all ATEM switchers?
A: Yes, it is designed to work with all ATEM switchers through the ATEM Software Control software.

Q: Can I use the ATEM Micro Camera Panel without a wired connection?
A: Yes, thanks to the integrated Bluetooth connectivity, it can be used wirelessly.

Q: What is the battery life of the built-in battery?
A: The battery life is approximately 6 hours under normal use.

Q: Do I need to install any specific drivers for use?
A: No, it is compatible with macOS and Windows without the need to install additional drivers.
